Hollyland Cosmo C1 SDI/HDMI Wireless Video Transmission System

Rs. 67,499.00
This product is Out of stock


Key Features:
  • Wireless Video Transmitter/Receiver Set
  • Transmitter HDMI/SDI Input, SDI Loop Out
  • Receiver HDMI & 2 x SDI Outputs
  • OLED Screen, USB Type-C Power Input
  • 1000' Line-of-Sight 1080p60 Transmission
  • 5.1 to 5.9 GHz Frequency Range
  • AES-128 Encryption, 40 ms Latency
  • L-Series Battery Plates on TX/RX
  • DC Adapter Power or Optional Battery

The Cosmo C1 SDI/HDMI Wireless Video Transmission System from Hollyland allows you to transmit up to 1080p60 video via HDMI/SDI inputs up to 1000' line-of-sight with a low 40 ms latency to an HDMI or dual SDI outputs. The transmitter offers one HDMI input, one SDI input, and one SDI loop-through output, and the receiver offers two SDI outputs and one HDMI output.

The system operates on the 5 GHz frequency band and is encrypted to prevent video leakage. The system supports smart channel selection, allowing the system to choose the cleanest channel for transmission. It also supports UVC pull streaming. Both units also feature a bright, easy-to-read OLED display. Each unit is designed to be powered via an L-series battery plate, by the included D adapter, or with an optional USB power supply via the USB Type-C port. Four standard antennas and two mushroom antennas are supplied for the receiver and transmitter.

Additional Key Features:

  • Transmit up to a 1080p60 HDMI/SDI signal to an HDMI or dual SDI outputs
  • 1000' line-of-sight, uncompressed transmission with a low 40 ms latency
  • AES-128 encryption to prevent video leakage
  • Smart channel selection
  • Supports UVC pull streaming
  • SDI loop-through output on transmitter
  • 5 GHz frequency band
  • OLED screen
  • USB Type-C power input option
  • L-series battery plates on back of each unit
  • Power with included DC adapter or with optional USB adapter

Technical Specifications:

Antenna Ports

Transmitter/Receiver: 2 x RP-SMA Female

Video

Transmitter: 1 x BNC (3G-SDI) Input

Transmitter: 1 x HDMI Type A Input

Transmitter: 1 x BNC (3G-SDI) Loop Output

Receiver: 2 x BNC (3G-SDI) Output

Receiver: 1 x HDMI Type A Output

Embedded Audio

HDMI/SDI: 2-Channel

Audio

None

Power

Transmitter/Receiver: 1 x Coax (16 VDC) Input

Other I/O

Transmitter/Receiver: 1 x USB 3.1 / USB 3.2 Gen 1 (USB Type-C) Input

Encryption

128-Bit AES

Wireless Range

1000' / 304.8 m

Channel Bandwidth

40 MHz

Frequency Range

US: 5.1 to 5.9 GHz

Latency

40 ms

Video Format

HDMI/SDI

1080p: 60

Wireless Video Compression

Uncompressed

DC Input Power

6 to 16 VDC

Battery Type

Transmitter/Receiver: 1 x L-Series

Mounting

1 x Cold Shoe



In the Box:

  • Hollyland Cosmo C1 SDI/HDMI Wireless Video Transmission System
  • Cosmo C1 Transmitter
  • Cosmo C1 Receiver
  • 4 x Antenna
  • 2 x Mushroom Antenna
  • Shoe Mount
  • Pan/Tilt Mount with Shoe Mount
  • USB Type-C Adapter
  • DC Adapter
  • Expansion Accessory
  • Limited 1-Year Warranty
