Accsoon CineView SE Multi-Spectrum Wireless Video Transmission System

Rs. 45,600.00 Rs. 42,400.00
Key Features:
  • Wireless Video Transmitter/Receiver Set
  • Twin Image Transmission over 2.4 & 5 GHz
  • Mix up to 4 Receivers, Tablets & Phones
  • 1080p60 HDMI/SDI Transmission to 1200'
  • iOS/Android App with Zebra & LUT Support
  • 1.3" OLED Displays, >50ms Latency
  • L-Series Battery Support up to 12 Hours
  • Automatic Channel Selection, DC Input
  • Fanless Design, Aluminum Construction

The CineView SE Multi-Spectrum Wireless Video Transmission System from Accsoon has been updated from previous models with an even smaller and lighter form factor. With the SE, you can now send signal to a total of four devices simultaneously over distances up to 1200' with only a 50ms delay, and you can still transmit to any mix of receivers and iOS/Android smartphones and tablets.

Like other models, the CineView SE allows you to send a 1080p60 camera signal to the included receiver plus up to three mobile devices. This versatile wireless video transmission system provides a cost-effective way of allowing four people on set to monitor an HDMI or SDI camera signal. Its Quad technology allows you to transmit exact copies of your transmission over 2.4 and 5 GHz signals for redundant, high-quality images.

The included dedicated receiver is easy to set up and pair, and it features an HDMI and SDI output. The free-to-download companion app installs on a tablet or smartphone and it features image tools such as peaking, zebras, false color for exposure, and .cube 3D LUT overlay, and new features include Smart Sharpening and Onion Skin overlay. The transmitter and receiver feature DC power inputs, USB Type-C power inputs, and they also support an optional L-series battery that can power the set for up to 12 hours.

Wireless Transmission
Twin dual-band wireless technology transmits the same image on both 2.4 and 5 GHz frequencies at the same time

Latency less than 50ms
Long-distance transmission range of 1200'
One transmitter can simultaneously connect up to four devices such as receivers, smartphones, or tablets

Apps
  • Wireless remote monitoring via Accsoon Go App
  • Smart Sharpening tool for more accurate focusing
  • Onion Skin Overlay tool for precise repetition of shots and improved LUT loading and recording
  • Ability to multitask with the Go App on Split View when using a suitable iPad
  • High-end features like focus peaking, histogram, and false color

Twin Image Transmission
The system transmits two identical copies of your camera's video output on both 2.4 and 5 GHz frequencies at the same time. When these signals arrive at the receiver unit, they are instantly combined as needed to create the final high-quality video feed

Video Input/Output
  • HDMI and SDI inputs on the transmitter
  • HDMI and SDI outputs on the receiver
  • Up to Full HD 1080p60 video and high-quality audio transmission

Design
  • The CineView SE system is even smaller and lighter than ever, with both transmitter and receiver weighing in at just 7.4 each
  • Fanless design for silent operation
  • Power by L-series/NP-F type battery, USB Type-C input, or DC input
  • Bright OLED screen
  • Durable aluminum construction

Technical Specifications:

Video I/O

Transmitter: 1 x HDMI Input

Transmitter: 1 x BNC (3G-SDI) Input

Receiver: 1 x HDMI Output

Receiver: 1 x BNC (3G-SDI) Output

Embedded Audio

HDMI/SDI

Audio I/O

None

Power

Transmitter/Receiver: 1 x Barrel 2.1 mm (16.8 VDC) Input

Transmitter/Receiver: 1 x USB-C (5 VDC) Input

Encryption

None

Wireless Range

1200' / 365.8 m

# of Channels

20

Frequency Range

2412 to 2472 MHz

5180 to 5580 MHz

5660 to 5825 MHz

Latency

< 50 ms

RF Power

17 dBm

Wi-Fi

Wi-Fi 5 (802.11ac); Dual-Band (2.4 & 5 GHz)

Bluetooth

None

Video Format

HDMI/SDI/Wireless

1080p: 60/59.94/50/30/29.97/25/24/23.98

Audio Format

2-Channel 24-Bit 48 kHz PCM Audio

Timecode Support

No

DC Input Power

7.4 to 16.8 VDC

Battery Type

Transmitter/Receiver: 1 x L-Series

Power Consumption

Transmitter: 4.5 W (Typical)

Receiver: 3.5 W (Typical)

Mounting

1 x 1/4"-20 Female

Environmental Protection

None

Operating Temperature

22 to 72°F / -10 to 40°C

Material of Construction

Aluminum

Dimensions

Transmitter/Receiver: 4.1 x 2.6 x 1.3" / 10.5 x 6.6 x 3.2 cm

Weight

Transmitter/Receiver: 7.4 oz / 210 g, Including Antenna



In the Box:

  • Accsoon CineView SE Multi-Spectrum Wireless Video Transmission System
  • CineView Quad Transmitter
  • CineView Quad Receiver
  • Shoe Mount
  • Limited 1-Year Manufacturer Warranty
