Blackmagic Design Cintel Scanner C-Drive HDR Scanner with Capstans

Rs. 3,136,440.00



Key Features:
  • For 35mm, Super 35 & Anamorphic 35mm
  • 4096 x 3072 1.33 (4:3) Native Resolution
  • Thunderbolt 3 or PCIe Output
  • Capstan-Based Movement
  • Raw Output to DaVinci Resolve
  • Optional Plate for 16mm/Super 16mm
  • Optional Audio/KeyCode Reader Unit
  • UHD 4K & 1080p HDMI Monitor Output
  • 12-Stop Dynamic Range, 14-Stop HDR
  • For Print, Negative, Color & B&W Film

Access a wealth of existing film-based content using the Cintel Scanner S-Drive HDR G2 from Blackmagic Design. This industrial film scanner converts 35mm film to raw video output directly to your computer using an extremely fast Thunderbolt 3 or PCIe connection and gentle, capstan-based movement. The Cintel S-Drive Scanner is Mac, Windows, and Linux-compatible and can be updated to access future features.

Use the Cintel S-Drive Scanner's pipeline to DaVinci Resolve for advanced color correction, dirt and dust removal, noise reduction, and additional restoration functions. An HDMI output enables you to monitor, focus, and align your footage in HD as it is scanned and separately available 16mm and audio/KEYKODE units provide expanded scanning options.

Note: Please note that the Cintel scanner weighs over 130 pounds/60 kg and is clearly too heavy to be unpacked by one person.
Convert Existing Film Content to UHD 4K
  • Scans 35mm film with native 4K UHD resolution to create video content
  • 35mm, Super 35, and anamorphic 35mm
  • Optional plate for 16mm and Super 16
  • Optional audio and KeyCode reader
Direct Computer Connection
Fast Thunderbolt 3 and external PCIe interfaces for connecting to Mac, Windows, and Linux based computers

Capstan Movement
Gentle, rubber capstan-based film handling

HDR Imaging
  • Captures the super high dynamic range of film14-stop dynamic range in HDR
Realtime Scanning
  • Realtime scanning rate via Thunderbolt 3 connection
  • Length of film equals the time needed to scan
DaVinci Resolve Color Correction
  • Outputs raw video directly to DaVinci Resolve
  • Automatic dirt removal, dust removal, de-flickering
  • Spot repair, noise reduction, and additional tools
Film Stock Support
  • For print, negative, color, and monochrome (B&W) film
  • For interpositive and internegative film
RGB LED Light Source
  • Super-bright, spherical RGB LED light source
  • Illuminates your film source without thermal stress
  • Diffusing sphere reduces the visibility of dust and scratches
Streamlined Design
  • Can be wall-mounted or used on a desktop
  • Integrated cleaning rollers
  • Updated digital servo motors
  • Sliding doors
Sync & Timecode Port
A bi-phase sync/timecode output port can be used with audio followers and other components

Technical Specifications:

Film/Print Format

35mm (2, 3, 4 Perforations) Rolls, Super 35 (2, 3, 4 Perforations) Rolls, 16mm Rolls, Super 16 Rolls

Light Source

1 x LED

Output Video Resolution

4096 x 3072 at 30 fps

Computer Interface

Thunderbolt 3 (USB Type-C)

PCIe 2.0 x4 (Proprietary)

Video

HDMI Type-A

OS Compatibility

Linux

macOS 10.14.15 or Later

Windows 10

*As of November, 2021: Check with manufacturer for the most up-to-date compatibility

Power Source

AC Adapter

AC Input Power

100 to 240 VAC, 50 / 60 Hz

Power Consumption

200 W

Operating Temperature

64 to 82°F / 18 to 28°C

Operating Humidity

65%

Dimensions (W x H x D)

79.13 x 34.64 x 14.17" / 200.99 x 87.99 x 35.99 cm

Weight

132 lb / 59.9 kg



In the Box:

  • Blackmagic Design Cintel Scanner C-Drive HDR Scanner with Capstans
  • 35mm Gate
  • 2 x Film Spool
  • 8 x 1mm Reel Spacer
  • Desk Stand
  • DaVinci Resolve Studio Software
  • Limited 1-Year Warranty
