The interface comes with a complete recording toolkit with Pro Tools Artist, Ableton Live Lite, and Focusrite's Hitmaker Expansion software bundle; featuring Auto-Tune Access for Vocals, Softube Marshall Silver Jubilee 2555 for guitar, Native Instruments MASSIVE synth, and more.
The Hitmaker Expansion bundle has everything you need to bring big studio sound to your songs, with an unbeatable range of record-making studio tools from the biggest names in the business:
Technical Specification:
Channels of I/O
Analog:4 Inputs / 4 Outputs at 192 kHz
Maximum Sampling Rate
192 kHz / 24-Bit
Number of Microphone Inputs
2
Analog Audio I/O
2x Combo XLR-1/4" 3-Pin Balanced/Unbalanced Mic/Line/Hi-Z Input (Front Panel)2x 1/4" TRS Balanced/Unbalanced Line Input4x 1/4" TRS Balanced/Unbalanced Line/Monitor Output1x 1/4" TRS Headphone Output (Front Panel)
Digital Audio I/O
No
Host Connection
1x USB-C
OS Compatibility
macOSWindows
Power Requirements
USB Bus Power, USB Power Adapter (Not Included)
Built-In DSP
Built-In Microphone
Input Level Adjustment
2x Knob
Expansion Slots
Gain/Trim Range
Mic/Line Inputs:Up to +69 dBHi-Z Inputs:62 dB
Phantom Power
48 V, Selectable On/Off
Host Connection Protocol
USB 2.0
USB (Non-Host)
1x USB-C (Power Input)
Sync I/O
Network I/O
MIDI I/O
1x DIN 5-Pin Input1x DIN 5-Pin Output
Wireless
Frequency Response
Combo XLR-1/4" Mic Inputs:20 Hz to 20 kHz ±0.06 dBCombo XLR-1/4" Line Inputs:20 Hz to 20 kHz ±0.05 dBCombo XLR-1/4" Hi-Z Inputs:20 Hz to 20 kHz ±0.15 dB1/4" Line Inputs:20 Hz to 20 kHz ±0.02 dB
Maximum Input Level
Combo XLR-1/4" Mic:16 dBuCombo XLR-1/4" Line:22 dBuCombo XLR-1/4" Hi-Z:12 dBu1/4" Line:22 dBu
Maximum Output Level
1/4" Line:+16 dBu
Headphone Output Power
1/4":57 mW into 33 Ohms27 mW into 300 Ohms
Impedance
Combo XLR-1/4" Mic Inputs:3 KilohmsCombo XLR-1/4" Line Inputs:60 KilohmsCombo XLR-1/4" Hi-Z Inputs:1 Megohms1/4" Line Inputs:60 Kilohms1/4" Line Outputs:100 Ohms1/4" Headphone Outputs:< 11 Ohm
Dynamic Range
Combo XLR-1/4" Mic Inputs:116 dBACombo XLR-1/4" Line Inputs:115.5 dBACombo XLR-1/4" Hi-Z Inputs:113 dBA1/4" Line Inputs:115.5 dBA1/4" Line Outputs:120 dB1/4" Headphone:112 dB (at 33 Ohms)115 dB (at 300 Ohms)Digital A/D Converters:130 dBDigital D/A Converters:130 dBA
THD+N
Combo XLR-1/4" Mic Inputs:-100 dB (at 8 dB Gain)Combo XLR-1/4" Line Inputs:-100 dB (at 8 dB Gain)Combo XLR-1/4" Hi-Z Inputs:-80 dB (at Minimum Gain)1/4" Line Inputs:-105 dB1/4" Line Outputs:-112 dB1/4" Headphone Outputs:-99 dB (at 33 Ohms)-108 dB (at 300 Ohms)Digital A/D Converters:-115 dBDigital D/A Converters:-115 dB
EIN
Combo XLR-1/4" Mic Inputs:-127 dBu A-Weighted
Sample Rates
44.1 / 48 / 88.2 / 96 / 176.4 / 192 kHz
Bit Depths
24-Bit
Sync Sources
Internal
Media/Memory Card Slot
Mobile App Compatible
Yes: iPadOS Only
AC/DC Power Adapter
5 VDC at 3 A (Included)
Power Consumption
7.5 W
Dimensions
7.09 x 5.08 x 2.32" / 18.01 x 12.9 x 5.89 cm
Weight
1.8 lb / 816.0 g
In the Box:
