Connects an HDMI cable to another HDMI cable or display
Supports 4K@60Hz resolution
Convenient 90° downward angle allows for easy connection in the most inconvenient places; e.g., tight corners, difficult ports
Easily connect around difficult corners or to hard-to-reach ports. The ManhattanHDMIAdapter is ideal for navigating around difficult corners or connecting to the most inaccessible device ports. This HDMI Adapter allows 4K resolution and a bandwidth of 10.2 Gbps at 340 MHz.
Connects an HDMI cable to another HDMI cable or display
Supports 4K@60Hz resolution
Convenient 90° downward angle allows for easy connection in the most inconvenient places; e.g., tight corners, difficult ports
Gold-plated contacts for best performance
Intended for use with Manhattan HDMI cables
Lifetime Warranty
Technical Specification:
Standards and Certifications:
RoHS2 compliant (Restriction of Hazardous Substances Directive, version 2).
ISO 9002 certified (quality management system standard).
General:
Bandwidth: 10.2 Gbps.
Frequency: 340 MHz.
Meets or exceeds existing HDMI standards.
Length: 4 cm (1.6 in.).
Connectors:
HDMI A female connector with 19-pin gold-plated contacts.
HDMI A male connector with 19-pin gold-plated contacts.
Electrical:
Current rating: 0.5 ADC.
Withstanding voltage: 300 VDC.
Insulation resistance: 5 MΩ.
Conductive resistance: 2 Ω.
Physical Specifications:
Overall length: 36 x 23 x 20 mm (1.4 x 0.9 x 0.8 in.).
