- UHD 4K30 Video Capture
- Output via Micro-HDMI & USB-A
- 1/2.8" CMOS Sensor, 1.98mm Focal Length
- 4G LTE Bonding with 2 SIM Slots, Wi-Fi
- SD Card Slot for Recording Capture
- 3" Touchscreen, App/Browser Control
- Can Add Logos, Titles, Scoreboards
- 3.5mm Stereo Analog Audio Input/Output
Capture, record, and livestream from any location with the A5 4K Streaming Camera with 4G Bonding from MiNE Media. This professional camera can capture stunning video with up to UHD 4K resolution and output via HDMI, USB for streaming, Wi-Fi, or via optional 4G LTE SIM cards. The camera features two SIM slots that can bond with the Wi-Fi connection to transmit simultaneously to redundant destinations. The camera also allows you to add logos, titles, and even scoreboards for event production, live broadcasts, and sporting events.
The compact camera features a 1/2.8" Sony CMOS sensor for crystal-clear imagery, and it features a fixed lens with a 1.98mm focal length for a wide angle with sharp focus on the entire scene. The camera also features a 3.5mm stereo analog audio input and output, so you can add audio to your capture or output audio to headphones, a mixer, or speakers. You can also record your streams using the built-in SD card slot.
Outputting your video locally is made easy with a micro-HDMI output, as well as a USB output to connect to a local computer for additional web streaming options via an app. A 3" touchscreen on the back allows you to control the camera's settings, and you can also control the camera via a browser or mobile app using a Wi-Fi connection.
- 1/2.8" Sony CMOS sensor
- 1.98mm focal length
- Up to 2160p30 streaming and recording
- 3" touchscreen interface
- 4G LTE bonding with two built-in SIM slots and Wi-Fi
- SD/TF card slot for recording
- 3.5mm stereo audio input and output
- Micro-HDMI output
- USB-A port for additional network connection
- Browser and mobile app control
- Add logos, titles, and scoreboards
Technical Specifications:
Image Sensor |
1/2.8"-Type CMOS |
Sensor Resolution |
Effective: 8 Megapixel |
Focal Length |
1.98mm |
Fixed Focus |
Yes |
Angle of View |
Horizontal 110.5° Vertical 76.3° |
Media/Memory Card Slot |
Single Slot: SD/SDHC/SDXC |
Video Format |
3840 x 2160p at 25/30 fps (20 Mb/s H.264/AVC, H.265/HEVC) 1920 x 1080p at 24/30/50/60 fps (H.264/AVC, H.265/HEVC) |
Audio Format |
AAC |
Display Size |
AAC: 48.0 kHz |
IP Streaming |
RTMPS, SRT 3840 x 2160 at 25p, 30p 1920 x 1080 at 25p, 30p, 50p, 60p (3200.00 to 20,000.00 Kb/s) |
Display Type |
Fixed Touchscreen LCD |
Size |
3" |
Built-In Mic |
Yes |
Built-In Speaker |
Yes |
Video I/O |
1 x Micro-HDMI (Unspecified Signal) Output 1 x USB-A 2.0 Output |
Audio I/O |
1 x 1/8" / 3.5 mm TRS Stereo Mic/Line Input 1 x 1/8" / 3.5 mm TRS Stereo Headphone/Line Output |
Power I/O |
1 x USB-C Input |
Wireless |
Wi-Fi Video Output, Control |
Mobile App Compatible |
Yes: Android & iOS *As of December, 2022: Check with manufacturer for the most up-to-date compatibility |
Color |
Black |
Battery |
Built-In Lithium-Ion Battery, 5 VDC, 8000 mAh |
Charging Method |
USB |
Power Consumption |
Operating: 8 W |
Operating Temperature |
32 to 104°F / 0 to 40°C |
Dimensions (W x H x D) |
5.1 x 3.1 x 2.4" / 130 x 80 x 60 mm |
Weight |
14.1 oz / 400 g |
In the Box:
- MiNE Media A5 4K Streaming Camera with 4G Bonding
- Limited 1-Year Manufacturer Warranty
