Teradek Bolt 4K LT 750 3G-SDI/HDMI Wireless Receiver

Rs. 277,500.00
Key Features:
  • Receive Video from up to 750'
  • HDMI and 3G-SDI Outputs, Zero Delay
  • Receive 4K30 Video, 10-Bit 4:2:2
  • Compatible with Bolt 4K Transmitters
  • AES-256 Encryption, 5 x Antennas
  • Bluetooth Mobile App, Spectrum Analyzer

Receive lossless HD video from up to 750' line-of-sight with the Bolt 4K LT 750 3G-SDI/HDMI Wireless Receiver from Teradek. The unit can wirelessly receive up to 4K30 video with 10-bit 4:2:2 HDR support, features a bright OLED display, and outputs video via HDMI and 3G-SDI.

The receiver supports transmissions of up to 4K30 video from any Bolt 4K series transmitter, which can simultaneously transmit to up to six receivers. It features improved metadata, range, and compatibility over its predecessors. The built-in AES-256 encryption and RSA 1024 key pairing protects your video from prying eyes, while noise rejection keeps your video clean no matter how many devices are using the wireless spectrum. The Bolt LT system also supports the transmission of timecode and start/stop triggers.

The Bolt 4K LT units are all cross-compatible, so you can transmit to different Bolt 4K series receiver models. The system also supports an iOS/Android app that easily connects via Bluetooth, which provides a spectrum analyzer, channel selection tools, and remote configuration. There are 1/4"-20 and M3 mounting threads to mount your receiver on a variety of monitors or rigs.

  • Cross-compatible with all Bolt 4K series devices over 5 GHz signal spectrum
  • Wirelessly receive up to 4K30 video and output 1080p via 3G-SDI and 4K via HDMI
  • Supports Rec 2020 HDR in 10-bit 4:2:2 color gamut
  • Smaller and lighter chassis design than other Bolt receivers
  • The receiver features five antennas
  • AES-256 encryption and RSA 1024 key pairing support
  • Wireless iOS/Android app via Bluetooth features a spectrum analyzer and remote configuration

Technical Specifications:

Antenna I/O

5 x RP-SMA Female

Embedded Audio

SDI: 2-Channel

HDMI: 2-Channel

Encryption

256-Bit AES

Wireless Range

750' / 228.6 m (Line-of-Sight)

# of Channels

13 (40 MHz)

25 (20 MHz)

Channel Bandwidth

40 MHz, 20 MHz

Frequency Range

Non-DFS Frequencies

US: 5.19 to 5.23 GHz

US: 5.75 to 5.79 GHz

DFS Frequencies

US: 5.27 to 5.67 GHz

Latency

< 0.01 ms

RF Power

17 dBm

Audio Format

2-Channel 24-Bit 48 kHz LPCM Audio

Wireless Video Compression

Uncompressed

Timecode Support

Yes

Built-In Battery

No

Operating Temperature

32 to 104°F / 0 to 40°C



In the Box:

  • Teradek Bolt 4K LT 750 3G-SDI/HDMI Wireless Receiver
  • 2-Pin to D-Tap Power Cable (18")
  • BNC Cable (10")
  • Micro-USB to USB Type-A Cable (36")
  • Ultra-Thin HDMI Type A Cable (18")
  • 18W AC Adapter Cable with 2-Pin Connector (6')
  • 5 x Antenna
  • Limited 1-Year Warranty
