Belden Security & Commercial Audio Plenum-CMP 2-20 AWG Cable (6400UE)
Security & Commercial Audio Cable, Plenum-CMP 2-20 AWG stranded bare copper conductors with Flamarrest® insulation, Flamarrest® jacket with ripcord
Technical Specifications:
|
Suitable Applications |
Intercom/PA Systems, Sound/Audio Systems |
|
|
|
|
CONDUCTOR |
|
|
Element |
Conductor(s) |
|
Number of Element |
2 |
|
Size |
20 AWG |
|
Stranding |
7x28 |
|
Material |
BC - Bare Copper |
|
|
|
|
INSULATION |
|
|
Element |
Conductor(s) |
|
Material |
PVC - Polyvinyl Chloride |
|
Nom. Thickness |
0.009 in (0.23 mm) |
|
Nom. Insulation Diameter |
0.054 in (1.4 mm) |
|
Color Code |
Black, Red |
|
|
|
|
OUTER SHIELD |
|
|
Shield Type |
- |
|
Material |
No Shield |
|
Coverage |
- |
|
Drainwire Type |
- |
|
|
|
|
OUTER JACKET |
|
|
Material |
PVC - Polyvinyl Chloride |
|
Nom. Thickness |
0.015 in (0.38 mm) |
|
Nom. Diameter |
0.134 in |
|
Ripcord |
Yes |
|
Overall Cable Diameter (Nominal) |
0.134 in |
|
|
|
|
ELECTRICALS |
|
|
Element |
- |
|
Nom. Conductor DCR |
10.2 Ohm/1000ft |
|
Nom. Capacitance Cond-to-Cond |
30 pF/ft (98 pF/m) |
|
Nom. Capacitance Cond-to-Other (Conds + Shield) |
- |
|
Max. Current |
3.75 Amps per Conductor at 25ºC |
|
|
|
|
UL Voltage Rating |
300 V |
|
|
|
|
TEMPERATURE |
|
|
UL Temperature |
75°C |
|
Operating |
-20°C To +75°C |
|
|
|
|
BEND RADIUS |
|
|
Stationary Min. |
1.34 in (34.0 mm) |
|
Installation Min. |
1.34 in (34.0 mm) |
|
Max. Pull Tension |
25.2 lbs (11.4 kg) |
|
Bulk Cable Weight |
12 lbs/1000ft |
