Boost your business's network switching capacity with the GS310TP S350 Series 8-Port Gigabit PoE Smart Managed Switch from Netgear. Boasting a switching bandwidth up to 20 Gb/s and a packet forwarding rate up to 14.8 Mpps, the GS310TP comes equipped with eight Gigabit Ethernet ports and two Gigabit SFP ports. The eight Gigabit Ethernet ports support PoE+ (Power over Ethernet), ideal for transmitting data and power over a single cable, with a total PoE budget of 55W. 802.1x support helps to ensure secure access for authorized users, while 802.1p-based prioritization helps to optimize network performance by prioritizing business-critical traffic. A web-based UI allows for remote management, while the switch's fanless design helps to ensure quiet operation.
Technical Specifications:
Inputs/Outputs
8 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) PoE+
2 x 10/100/1000 Mb/s Gigabit SFP
Layer Services Supported
Layer 2 Support
Supported Protocols
IGMP Snooping
IPv4
IPv6
Link Aggregation
Port Mirroring
MAC Filtering
SNMPv1
SNMPv2c
SNMPv3
Queuing
Weighted Round Robin (WRR)
Transmission Method
Store-and-Forward
Jumbo Frames Support
10,000 Bytes
MAC Address Table Size
8K
Multicast Groups
256
VLAN Groups
64
Security Features
DoS Attack Prevention
Kensington Lock Support
RADIUS Authentication
Access Control List
100
SNMP Support
1, 2c, 3
Supported IEEE Standards
802.1ab, 802.1d, 802.1p, 802.1q, 802.1s, 802.1w, 802.1x, 802.3, 802.3ab, 802.3ad, 802.3af, 802.3at, 802.3az, 802.3u, 802.3x, 802.3z
Latency
3.4 to 4.2 µs
Forwarding Rate
14.8 Mpps
Switching Bandwidth
20 Gb/s (Non-Blocking)
Priority Queues
8
Packet Buffer
512 kB
Flash Memory
32 MB
Memory
128 MB
Power Draw
69.3 W (Active)
3.3 W (Idle)
DC Input Power
VDC at 1.25 A
PoE Power Budget
55 W
Power Supply Type
External
Operating Temperature
32 to 104°F / 0 to 40°C
Operating Humidity
95%
Storage Temperature
-20 to 70°F / -28 to 21°C
Storage Humidity
Operating Altitude
10,000' / 3048 m
Storage Altitude
Certifications
BSMI, CB, CCC, CE, EN60950-1, FCC, RCM, UL, VCCI
*as per Manufacturer
Cooling System
Passive
Mean Time Between Failures (MTBF)
1,081,119 Hours
Indicator Lights
Link/Activity, PoE, Power, Speed
Dimensions
9.29 x 3.98 x 1.18" / 236 x 101 x 30 mm
Weight
1.32 lb / 0.6 kg
