Suitable Applications

Premise Horizontal Cable, Ethernet 1000BASE-T, Ethernet 100BASE-TX, Ethernet 10BASE-T, PoE++, PoE+, PoE

CONDUCTOR

Size

23 AWG

Stranding

Solid

Material

BC - Bare Copper

Number of Pairs

4

INSULATION

Material

PO - Polyolefin

Color Code

White/Blue Stripe & Blue, White/Orange Stripe & Orange, White/Green Stripe & Green, White/Brown Stripe & Brown

OUTER JACKET

Separator

Dielectric Tape (Patented)

Material

PVC - Polyvinyl Chloride

Material Trade Name

Flamarrest

Nom. Diameter

0.224 in (5.69 mm)

Ripcord

Yes

Overall Cable Diameter (Nominal)

0.224 in (5.69 mm)

ELECTRICALS

Max. Conductor DCR

78 Ohm/km (24 Ohm/1000ft)

Max. Capacitance Unbalance

330 pF/100m

DELAY

Frequency

100 MHz

Max. Delay

537.6 ns/100m

Max. Delay Skew

35 ns/100m

Nom. Velocity of Prop.

72%

UL Voltage Rating

300 V (CMP), 300 V (CL3P)

TEMPERATURE

UL Temperature

90°C

Operating

-20°C To +75°C

Installation

0°C To +50°C

Storage

-20°C To +75°C

BEND RADIUS

Stationary Min.

1.0 in (25 mm)

Installation Min.

2.25 in (57.2 mm)

Max. Pull Tension

25 lbs (11 kg)

Bulk Cable Weight

26 lbs/1000ft
