Belkin Thunderbolt 3 Dock Core

Rs. 0.00
This product is Out of stock

WORLD'S FIRST THUNDERBOLT™-CERTIFIED DUAL-POWERED DOCK

The Thunderbolt 3 Dock Core brings the speed, high-definition and performance of Thunderbolt technology to Mac and Windows laptops. With all the power and versatility of Thunderbolt 3, plus ports to connect multiple peripherals to a Thunderbolt laptop, this dock is a streamlined way to create an expanded, high-performing desktop through a single tethered cable.



CONNECT AN ENTIRE DESKTOP THROUGH A SINGLE CABLE

The tethered 6-inch Thunderbolt 3 cable connects multiple peripherals to your laptop, with ports for monitors, mouse, USB stick, keyboards, speakers, hard drives and more.

SIDE 1:

    1. 1 x DisplayPort™ 1.4 connects to high-resolution monitors/displays (for resolutions, see table below)
    2. 1 x HDMI (HDMI 2.0) port
    3. Gigabit Ethernet connection

SIDE 2:

    1. Tethered Thunderbolt 3 cable connects to laptop
    2. 1 x USB-C PD port (input)

SIDE 3:

    1. Audio in/out for mic and speaker support
    2. 1x USB-A 3.2 Gen 2(10Gbps) and 1x USB-A 2.0 ports for devices that connect via USB-A such as a USB stick, mouse, keyboard or printer



    WORKS WITH THUNDERBOLT 3 DEVICES

    The Thunderbolt 3 Dock Core is an ideal single-dock solution for businesses using MacBooks running Mac OS, and laptops running Windows. This broad compatibility is also ideal for shared work environments or temporary workstations where laptop users are looking for a high-performing workstation with minimal set up.*

    See table below for system requirements.


    DISPLAY CONFIGURATIONS

    PORTS

    Mac

    macOS Sierra 10.12 or later

    Thunderbolt 3 port

    PC (Windows)

    Windows 10 or later

    Thunderbolt 3 port





    DUAL 4K MONITOR SUPPORT

    Supports dual 4K 60Hz monitors for a versatile desktop configuration, via a dedicated DisplayPort and an HDMI 2.0 port. Also supports a single 5K monitor at 60Hz and capable of reaching 8K 30Hz.

    Please see the table below for specific resolution capabilities for all monitor combinations.


    SINGLE MONITOR SUPPORT

    DUAL MONITOR SUPPORT

    Thunderbolt 3 Laptop

    Laptop running High Bit Rate 3:

    8K (7680 x 4320) @ 30Hz


    Laptop running High Bit Rate 2:

    5K (3840 x 2160) @ 60Hz

    Laptop running High Bit Rate 3:

    4K (3840 x 2160) @ 60Hz


    Laptop running High Bit Rate 2:

    4K (3840 x 2160) @ 30Hz





    DUAL-POWERED FUNCTIONALITY

    When the Thunderbolt 3 dock is connected to a laptop, it powers peripheral devices connected to the dock without the need for a separate power cable. Keep your laptop charged by connecting its existing power supply unit (60W recommended) to the USB-C PD port on the Thunderbolt dock.

    Thunderbolt and the Thunderbolt logo are trademarks of Intel Corporation or its subsidiaries.



    2-YEAR WARRANTY

    Our Thunderbolt 3 Dock is backed by a 2-year product warranty for added peace of mind.



    Specs:

    1. L: 100mm/3.94in
    2. W: 100mm/3.94in
    3. H: 30mm/1.18in
    • Cable length: 20cm/7.87in
    • Weight: 213.8g



    At a Glance:

    • World's first Thunderbolt-certified dual-powered dock
    • Compatible with Thunderbolt-certified Mac and Windows laptops with a Thunderbolt 3 port
    • Connect multiple devices to your laptop through one dock, including monitors, USB stick, mouse, keyboards, internet, hard drives and more
    • Supports dual 4K UHD displays @ 60Hz
    • 7 ports: 1 x Thunderbolt 3, 1 x USB-C PD, 1 x DisplayPort, 1 x HDMI, 1x USB-A 3.2 Gen 2(10Gbps), 1x USB-A 2.01, 1 x Audio in/out, 1 x Gigabit Ethernet
    • Supports pass-through power from a laptop to connected devices
    • Connect laptop’s power supply unit (60W recommended) to the dock to power the laptop
    • Protected by 2-year product warranty



    Package Includes:

    • Thunderbolt 3 Dock Core



    Specifications

    Features

    USB-C Power Delivery

    Cable connector

    DisplayPort

    HDMI

    USB-C

    3.5mm

    USB-A

    Thunderbolt 3



    Manufacturer's SKU: F4U110bt
