Key Features:
- For DaVinci Resolve 17 Systems
- Requires Fairlight Audio Accelerator
- 192 Channels of MADI I/O
- 24-Bit / 48 kHz Resolution
- Three 75-Ohm BNC MADI Inputs
- Three 75-Ohm BNC MADI Outputs
- Uses No Additional PCIe Bandwidth
- Half-Length PCIe x4 Board
Connected to your Fairlight Audio Accelerator, the Blackmagic Design Fairlight PCIe Audio MADI Upgrade adds 192 channels of MADI I/O to your DaVinci Resolve 17 system, raising the total MADI channel count to 256 inputs and outputs. This half-length card uses no additional PCIe bandwidth and hooks up to the Fairlight Audio Accelerator (required and available separately) through the supplied SATA cables.
The Fairlight Audio MADI Upgrade operates at 24-bit / 48 kHz resolution. It features three 75-ohm BNC MADI inputs and three 75-ohm BNC MADI outputs to provide extreme channel counts while using minimal physical space.
MADI Inputs
MADI Outputs
Audio Channels
Bit Depth and Sample Rate
PCI Form Factor
Power
Hardware Requirements
PCIe Requirements
Form Factor |
Internal |
Display |
None |
Channels of I/O |
MADI: 192 Inputs / 192 Outputs at 48 kHz |
Max Sample Rate/Resolution |
48 kHz / 24-Bit |
Number of Mic Preamps |
None |
Solo/Mute |
None |
Pad |
None |
High-Pass Filter |
None |
Expansion Slots |
None |
Analog Audio I/O |
None |
Phantom Power |
None |
Digital Audio I/O |
3 x BNC Coaxial MADI Input 3 x BNC Coaxial MADI Output |
Host Connection / USB |
1 x PCIe |
USB (Non-Host) |
None |
Sync I/O |
None |
Network I/O |
None |
MIDI I/O |
None |
Wireless Connectivity |
None |
Memory Card Slot |
None |
Impedance |
Coaxial MADI : 75 Ohms |
Sample Rates |
48 kHz |
Sample Rate Conversion |
None |
Bit Depths |
24-Bit |
Sync Sources |
MADI |
OS Compatibility |
macOS 10.15 or Later Windows 10 (64-Bit) |
Included Software |
None |
Supported Drivers/API & Plug-Ins |
Proprietary |
Mobile Device Compatibility |
None |
Required Hardware |
PCIe Card Slot |
Power Requirements |
PCIe |
Power Consumption |
4 W |
Operating Humidity |
0 to 90% |
Operating Temperature |
32 to 104°F / 0 to 40°C |
Storage Temperature |
-4 to 140°F / -20 to 60°C |
Dimensions |
3.07" / 7.8 cm (Half-Size PCIe Card) |
Weight |
4.9 oz / 139.0 g |
In the Box:
- Blackmagic Design Fairlight PCIe Audio MADI Upgrade
- 3 x SATA Cables (11.8")
- Computer Power Cable
- Limited 1-Year Warranty
