Datavideo 4-Channel Long-Range HDBaseT Receiver with HDMI, 3G-SDI Outputs

Rs. 320,960.00 Rs. 299,990.00
On Special Order (Expected shipping: 2-4 weeks)
Key Features:
  • Link 1080P Cameras
  • Converts IP Video to HDMI, 3G-SDI Output

This 4-Channel DataVideo Long-Range HDBaseT Receiver supplies power, 1080p video, and camera control to up to 4 devices up to 328' distance. It simultaneously outputs HDMI, 3G-SDI, RS-422, and IP control signals.

Seamlessly add HDBaseT to your Workflow
HBT-50 can power PTZ video cameras via PoE, transmit signals over a single ethernet cable to and from the camera, and can be used to remotely control various camera parameters such as iris, presets, etc. Most importantly, it can output HDMI and SDI signals to your switcher.

Integrate Camera Control, Switcher, and Recorder Operations
HBT-50 transmits HDMI and SDI signals as well as camera control. With the HBT-50, the system can be integrated as a camera controller, video switcher, and ISO recorder.

Remote Control
Remote control of camera functions via RS-422 or DVIP with up to 4 cameras simultaneously up to 328'.

HDBaseT
HDBaseT allows you to transmit video, control, tally, and power over a single Cat 6 cable. This means you no longer need to run multiple cables for your cameras.

Technical Specifications:

Inputs

4 x RJ45 (HDBaseT)

Outputs

4 x HDMI (HDMI 2.0)

4 x BNC (3G-SDI)

Other I/O

4 x RJ45 RS-232, RS-422

1 x RJ45 HDBaseT

HDCP Support

None

EDID Support

None

Max Transmission Distance

1080p at 60 Hz:

328.1' / 100 m

Video Format

RJ45 Input

1080p: 23.98/24/25/29.97/30/50/59.94/60 fps

1080i: 50/59.94/60 fps

Supported Cable Types

Cat 6a

Power Connector

1 x IEC C14 Input

PoE Support

Yes

Operating Temperature

32 to 104°F / 0 to 40°C



In the Box:

  • Datavideo 4-Channel Long-Range HDBaseT Receiver with HDMI, 3G-SDI Outputs
  • AC Cord
