The interface comes with a complete recording toolkit with Pro Tools Artist, Ableton Live Lite, and Focusrite's Hitmaker Expansion software bundle; featuring Auto-Tune Access for Vocals, Softube Marshall Silver Jubilee 2555 for guitars, Native Instruments MASSIVE synth, and more.
The Hitmaker Expansion bundle has everything you need to bring big studio sound to your songs, with an unbeatable range of record-making studio tools from the biggest names in the business:
Technical Specification:
Channels of I/O
Analog:2 Inputs / 2 Outputs at 192 kHz
Maximum Sampling Rate
192 kHz / 24-Bit
Number of Microphone Inputs
1
Analog Audio I/O
1x XLR 3-Pin Balanced Mic Input1x 1/4" TS Unbalanced Line/Hi-Z Input (Front Panel)2x 1/4" TRS Balanced Monitor Output1x 1/4" TRS Headphone Output (Front Panel)
Digital Audio I/O
No
Host Connection
1x USB-C
OS Compatibility
macOSWindows
Power Requirements
USB Bus Power, USB Power Adapter (Not Included)
Built-In DSP
Built-In Microphone
Input Level Adjustment
2x Knob
Expansion Slots
Gain/Trim Range
Mic/Line Inputs:Up to +69 dBHi-Z Inputs:62 dB
Frequency Response
XLR Mic Inputs:20 Hz to 20 kHz ±0.06 dB1/4" Line Inputs:20 Hz to 20 kHz 0.05 dB1/4" Hi-Z Inputs:20 Hz to 20 kHz 0.15 dB
Maximum Input Level
XLR Mic:9.5 dBu1/4" Line:22 dBu1/4" Hi-Z:12 dBu
Maximum Output Level
1/4" Line:+16 dBu
Headphone Output Power
1/4":32 mW into 33 Ohms22 mW into 300 Ohms
Impedance
XLR Mic Inputs:3 Kilohms1/4" Line Inputs:60 Kilohms1/4" Hi-Z Inputs:1 Megohms1/4" Line Outputs:200 Ohms1/4" Headphone Outputs:< 50 Ohm
Dynamic Range
XLR Mic Inputs:113 dBA1/4" Line Inputs:113 dBA1/4" Hi-Z Inputs:112 dBA1/4" Line Outputs:120 dB1/4" Headphone:112 dB (at 33 Ohms)115 dB (at 300 Ohms)Digital A/D Converters:120 dBDigital D/A Converters:130 dBA
THD+N
XLR Mic Inputs:-100 dB (at Minimum Gain)1/4" Line Inputs:-100 dB (at 8 dB Gain)1/4" Hi-Z Inputs:-80 dB (at Minimum Gain)1/4" Line Outputs:-100 dB (at Minimum Gain)1/4" Headphone Outputs:-97 dB (at 33 Ohms)-102 dB (at 300 Ohms)Digital A/D Converters:-110 dBDigital D/A Converters:-115 dB
EIN
XLR Mic Inputs:-127 dBu A-Weighted
Sample Rates
44.1 / 48 / 88.2 / 96 / 176.4 / 192 kHz
Bit Depths
24-Bit
Sync Sources
Internal
Media/Memory Card Slot
Mobile App Compatible
Yes: iPadOS Only
AC/DC Power Adapter
5 VDC at 900 mA
Power Consumption
4.5 W
Dimensions
5.63 x 3.78 x 1.79" / 14.3 x 9.6 x 4.55 cm
Weight
0.8 lb / 363.0 g
